Input Size: 0-350mm
Processed Materials: Iron ore, copper ore, gold ore, manganese ore,limestone, granite, basalt, andesite, quartz, silica, gypsum, volcanic rock, marble, river stone, gravel, coal etc.
Applications: Secondary medium & fine crusher in mining, quarry, mixing and batching plant, road and building construction, highway, railway and subway, and water conservancy.
We can design the primary crushing,secondary crushing,tertiary crushing and combine them with each other flexibly according to customers’ requirement.We will try our best to meet our customers’requirement.
Technical Data//Model | Y3S23G93E46Y55B |
Transportation size (mm) | 14700x2900x4350 |
Weight(t) | 45 |
Tire Configuration | Dualaxial |
Vibrating feeder | GZD 960×3800 |
Crusher 1 | PE400x600 |
Crusher2 | PYB900 |
Vibrating screen | 3YZS1237 |
Belt conveyer above screen | B500x14m |
Belt conveyer under screen | B650x6m |
Main belt conveyer | B650x9m |
Side belt conveyer | B500x4m / 2 |
Electric control (standard) | control box + control panel |
Support leg (standard) | 4 |
